Cute-WR-DP
LOCATION:HOME > PRODUCTS

Cute-WR-DP (Compact Universal Timing Node for White Rabbit with Dual Ports) is a WR node in FMC form factor.


There are three function modes for Cute-WR-DP.

  1. Normal mode (Cute-WR-DP-NM)
    • In Normal mode, Cute-WR-DP acts as a normal WR node with one SFP port (SFP0).
  2. Cascade mode (Cute-WR-DP-CM)
    • In CM mode, two ports act as one down-link (SFP1) and one up-link (SFP0) to support cascade topology. Two ports also support a simple switch function for normal Ethernet packets.
  3. Parallel mode (Cute-WR-DP-PM)
    • In PM mode both port act as down-link port connect to different WRS, provide redundancy to improve the reliability for safety related applications. The current firmware doesn't support this function.





It is an open hardware design licensed under CERN OHL 1.2

For more details, please visit the website on OHWR
